TRUMPF TruLaser Robot 5020 Robotic Laser Welding Cell

TRUMPF TruLaser Robot 5020 Robotic Laser Welding Cell Videos Available Upon Request Low-hour robotic laser welding cell equipped with a KUKA KR 30 HA six-axis robot, TRUMPF TruDisk solid-state disc laser, turn-tilt rotary positioner, dual-station worktable, programmable-focus welding optics and TeachLine optical seam-sensing system. Specifications Manufacturer: TRUMPF Model: TruLaser Robot 5020 Year: 2014 Machine Type: Robotic Laser Welding Cell Laser Type: TRUMPF TruDisk solid-state disc laser Laser Source: Reported as TruDisk 4001, 4,000 watts—subject to nameplate verification Robot: KUKA KR 30 HA High Accuracy Robot Axes: Six Laser-On Hours: 1,143 Robot Hours: 339.82 Maximum Workpiece Dimensions: 47.25" × 31.5" × 23.5" Rotating Table Capacity: 750 kg / 1,653 lbs. Side Station Capacity: 250 kg / 551 lbs. Extended Side Panels: 189" × 234" Welding Materials: Mild steel, stainless steel and aluminum Equipped With KUKA KR 30 HA High Accuracy six-axis robot TRUMPF TruDisk solid-state disc laser Laser power supply and chiller 30-meter fiber-optic laser delivery cable Turn-tilt rotary positioner KUKA DKP 400.1 turn-tilt positioner table 750 kg rotating-table capacity 250 kg side-station capacity Dual-station worktable Three-dimensional adapter plate Two-dimensional adapter plate BEO D70 welding optics 200 mm focal length Motorized programmable focus adjustment TeachLine optical sensor and camera Magnetic coupling between robot and optics head KTL axis-alignment set WeldLine Modular Argon gas valve Linear nozzle set Aerator nozzle set Media supply for DKP positioner Process-gas supply port Process-gas control interface DKP control interface Dual-station table control interface Compact suction, filtration and exhaust unit Tropical cooling package Class 1 safety enclosure Sliding access door Extended safety-enclosure side panels Machine Description The 2014 TRUMPF TruLaser Robot 5020 is a fully enclosed robotic laser welding cell designed for precision welding of complex three-dimensional components. The system combines a KUKA KR 30 HA High Accuracy six-axis robot with fiber-delivered TRUMPF TruDisk solid-state laser technology. The system includes a KUKA DKP 400.1 turn-tilt positioner and a separate dual-station table, allowing components to be positioned for multi-axis welding. The rotating table is rated for 750 kg, while the side station is rated for 250 kg. The BEO D70 welding optics feature motorized programmable focus adjustment. The TeachLine optical sensor and camera assist with seam location and compensate for workpiece or fixture variation. The cell also includes process-gas controls, filtration and exhaust, cooling equipment and a fully enclosed Class 1 safety system. The machine has exceptionally low reported usage, with 1,143 laser-on hours and 339.82 robot hours.
