Machine Specifications
Table Size:
48" x 20"
Machine Travels:
X-Axis: 40"
Y-Axis: 20"
Z-Axis: 20"
Table Top to Spindle:
4" – 24"
Throat Depth:
16.5"
Rapid Traverse Rates:
900 IPM (X & Y), 700 IPM (Z)
Cutting Feed Rates:
0.01 – 400 IPM
Spindle Nose:
#40 CT
Tool Magazine:
24-Station ATC
Max Tool Diameter:
3" (adjacent tools) / 6" (with empty pocket)
Max Tool Length:
15"
Machine Weight:
10,500 lbs.
Disclaimer
Preliminary specifications are provided for general guidance only and may change without notice.
They are believed to be accurate but are not guaranteed. All specifications, dimensions, capacities,
weights, and performance figures should be independently verified by the buyer prior to purchase or use.
Bridgeline Machinery Corp. makes no representations or warranties, express or implied, regarding the completeness,
accuracy, or suitability of any machine specifications, and shall not be liable for any errors or omissions.
